Coal mining lights are portable lighting devices specially designed for underground coal mining environments. These lights typically feature explosion-proof, waterproof, dustproof, and impact-resistant properties. Common styles include headlamps, handheld lights, and helmet-mounted lamps. Equipped with high-brightness LEDs, adjustable brightness levels, and smart battery systems, they provide essential visibility, improve worker safety, and enhance operational efficiency in dark and hazardous conditions.
| Feature / Model | GL12-A | GL5-B | GLC-6S | GLC-6 | GLC-6 Wireless | GLC-6 Series (A/B/C) |
|---|---|---|---|---|---|---|
| Type | Cordless | Corded | Cordless | Cordless | Wireless | Wireless |
| Main Light Source | 1× CREE LED + 2× SMD LEDs | 1× 3W CREE LED + 6× SMD LEDs | 1× LED + 2× auxiliary LEDs | LED + auxiliary | LED | 1W LED (main) + 0.4W auxiliary |
| Lumen Output | 348 lm | 216 lm | 232 lm | 232 lm | 232 lm | 232 lm |
| Brightness | 25,000 lux | 10,000 lux | 9,000–25,000 lux adjustable | 15,000 lux | 13,000–15,000 lux | 6,000 / 10,000 / 15,000 lux |
| Lighting Modes | 4 (Strong/Weak/Aux/SOS) | 1 main + 6 aux | 5 (Weak/Med/Strong/Aux/SOS) | 3 (Main/Aux/SOS) | 3 (Main/Aux/SOS) | 3 (Main/Aux/SOS) |
| Battery Capacity | 10.4Ah (Samsung) | 6.6Ah (18650 cells) | 6.8Ah (Panasonic) | 6.8Ah (Panasonic) | 6.8Ah | 5.2Ah / 6.8Ah |
| Working Time | 13–15 hrs | 13–16 hrs | 14–16 hrs (main) / >60h (aux) | 13–15 hrs | Up to 15 hrs | ≥13h / ≥14h / ≥15h |
| Charging Time | Fast 2A charge | 4 hrs | 6 hrs | 4–6 hrs | 4–6 hrs | 3.5h / 4h / 6h |
| Voltage | 3.7V | 3.7V | 3.7V | 3.7V | 3.7V | 3.7V |
| Weight | 450g | 418g | 200g | 217g | 217g | 217g (typical) |
| Material | Aluminum + anti-impact composite | — | PC housing | PC (Germany Bayer) | High-impact PC | Polycarbonate (Bayer) |
| Waterproof Rating | IP68 | IP67 | IP68 | IP68 | IP68 | IP68 |
| Explosion-Proof / Flame-Resistant | Yes | Yes | Yes | Yes | Yes | Yes |
| Charging Options | 2A charger | Cable | USB / Cradle / Rack | USB / Magnetic | USB / Cradle / Rack | USB / Cradle / Rack |
| Display | No | No | OLED | OLED | OLED | OLED |
| Smart Features | — | — | NFC, RFID (optional) | — | Auto low-battery switch to aux | — |
| Adjustable Angle | Yes (Comfort neck clip) | Yes | 45° | 90° | 90° | 90° |
| Certifications | IP68, Explosion-proof | CE, ATEX | CE, ATEX (optional) | CE, ATEX | Certified mining use | CE, ATEX |
| Warranty | 1 year | 1 year | 1 year | 1 year | 1 year | 1 year |
| MOQ | 2 pcs (sample) / 200 pcs (bulk) | 2–100 pcs | 2 pcs | 2 pcs | 2 pcs | 2 pcs |
Best for Harsh Environments
| Budget Corded Option
| Smartest Cordless Lamp
|
Lightweight OLED Option
| Most Versatile Wireless Option
|
| Product Model | Key Features | Application Scenario | Price Range (USD) |
|---|---|---|---|
| GL-TL01 Basic Mining Lamp | Single LED, IP65 waterproof, 6-hour runtime | Small mines, temporary use | $15 – $25 |
| GL-HL02 Headlamp Model | Dual LED, battery indicator, explosion-proof certified | Tunnel inspection, night shift | $30 – $45 |
| GL-CAP03 Helmet-Mounted Lamp | Integrated design, lightweight, replaceable battery | Long working hours, hot areas | $50 – $65 |
| GL-EX04 Explosion-Proof Lamp | Multi-mode brightness, IP68, hazardous gas certified | Gassy areas, safety-critical | $70 – $90 |
| GL-PRO05 Professional Model | GPS tracking, SOS signal, 12-hour runtime, high-lumen beam | Large mines, professional teams | $100 – $130 |
| Step | Description |
|---|---|
| 1. Needs Assessment | Define your mining conditions: underground depth, working hours, gas levels, explosion risks, and safety requirements. Decide whether you need basic headlamps or advanced models with tracking and SOS. |
| 2. Product Selection | Visit Green Lighting’s official website or catalog. Choose models based on lumen output, battery runtime, weight, certifications (ATEX, MSHA), and IP ratings (water/dust resistance). |
| 3. Quantity & Customization | Determine quantity needed. Green Lighting offers OEM/ODM services — logos, battery specs, beam distance, and color options can be customized for bulk orders. |
| 4. Request Quotation | Contact sales via email or inquiry form. Provide your model preferences, quantity, and customization needs to get accurate CIF/FOB pricing. |
| 5. Sample Order | For large purchases, it’s highly recommended to request 1–2 sample units for field testing to verify light performance and battery endurance in real mining conditions. |
| 6. Contract & Payment | After approval, confirm payment terms (T/T, LC), delivery time, warranty details, and sign the PI (Proforma Invoice). |
| 7. Manufacturing & Delivery | Production time varies by order size (normally 7–20 days). Products are shipped with user manuals, quality inspection reports, and compliance certificates. |
| 8. After-Sales Support | Green Lighting provides online technical support, spare battery packs, and component replacements within warranty (1–2 years depending on model). |
Always select mining lights with proper explosion-proof certifications (e.g., ATEX, MSHA, IECEx). These ensure compliance with mine safety standards and protect against gas ignition risks.
Longer battery life is critical for full shifts (8–12 hours). Lithium-ion batteries with smart protection chips offer better safety and reliability. Ask about battery cell brand and cycle life.
Miners, supervisors, and rescuers need different brightness levels. Entry-level lights may be sufficient for routine work, while inspection or rescue personnel need high-lumen models (>600 lm).
A lighter lamp reduces fatigue during long wear. Choose helmet-integrated or ergonomic models if the user works extended underground hours.
Before placing large orders, test sample units in your actual mine environment for heat dissipation, beam range, fog penetration, and button usability with gloves.
High-end models now offer GPS, wireless data transmission, or RFID tracking. Ideal for modern mines looking to integrate with digital monitoring systems.
Inquire about battery modules, charger availability, and whether parts can be replaced without tools. Some Green Lighting models are designed with easy maintenance in mind.
Green Lighting, a professional coal mining light manufacturer with 18 years of experience, offers a full range of high-performance coal mining lights for sale, these coal mining lgihts usually for underground safety and industrial use. Our lineup includes cordless cap lamps, corded high-lumen lights, IP68 waterproof models, explosion-proof designs, and ultra-lightweight miner headlamps. Each model is designed with attention to detail—from beam angles and LED lifespans to battery protection circuits and magnetic charging options. Prices range from $25 to $65 based on lumen output, battery size, and features. We provide full OEM/ODM services including custom logos, packaging, and mold design. Our coal mining lights are CE/ATEX certified and trusted by clients across the USA, South Africa, Peru, Chile, Russia, and Australia. Welcome to consult our expert team for tailored procurement solutions.
