Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting

Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting

  • Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting
  • Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting
  • Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting
  • Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting
Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting
Product Details:
Place of Origin: shenzhen ,China
Brand Name: GREEN LIGHTING
Certification: ATEX, CE., FCC.,SAA.,MSHA
Model Number: GST-2
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiated best price
Packaging Details: gift box. 15*10*8cm each box, 44*44*36cm each carton, 50pcs/carton, 15.5kg/carton
Delivery Time: 7-15 days
Payment Terms: Western Union, MoneyGram, T/T, L/C
Supply Ability: 100000PCS/month
Contact Now
Detailed Product Description
Material: PC Battery: 2.2Ah
Voltage: 3.7V Brightness: >4000 Lux
Illuminous: 117lum Charging Time: 3~5 H
Working Time: 13h Light Qty: 1 Main Led Light +6 Aux Led Light
Main Light Power: 1w Main Light Current: 200mA
High Light:

miners cap lamp

,

miners cap lamps cordless



Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting



1. Feature for Cordless Mining Lights



Wateproof grade : IP68
High Beam Brightness : >4000LUX

Anti-explosive grade : Ex ia
High Quality Material : Germany Bayer PC
Portable Light Weight : 171g , similar to the weight as a cell phone, more portable.
Multi-function lighting modes : main light - auxiliary light




Item Value
Model GST-2
Light source 1pc main light and 6pcs auxiliary lights
Battery capacity 2.2Ah
Rated Voltage 3.7V
Main light current 200mA
Power of the main light 0.93W
Illuminous 117LUM
Brightness of the main light 4000lux
Life span for main LED 100000hours
Battery cycles 1000 cycles
Working time 13 hours
Weight 171g
Water-proof grade IP68
Certified CE,ATEX,EXIB II M1





2. General Guide PICTURES



Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting 0







 Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting 1







3. Our products can be widely used for :

Outdoor Recreation Multi purpose LED hard hat headlamp , Miner Cap Lamp Hunting 2

  • camping, travelling, cycling
  • tool, maintenance lighting
  • fishery, diving, fire-fighting
  • military, architecture, living
  • furniture, farm lighting
  • night fishing, car-carrying, road and railway lighting, forest farm



4. Product Advantages:



Safety : Over-charging protection , over-discharging protection, protection in electrical short-circuit,

automatic power-off on the socket , 100,000 hours LED’s Lifetime

Portability : All-in-one structure, Small in size , light in weight (only 171g for whole product),

inductive charging, easy usage

Efficiency : more than 15hours at full brightness, over 80hours at back up led brightness.Over4000lux

Brightness

Environmental : Li-ion battery is free for maintenance, and the material of li-ion is environmental, use

1Watt high power LED as the main light, and 6pcs backup LED’s to save power

Economy : three times longer than lead and acid cap lamp and saving in maintenance makes the product

more compatible in price

Charger input power : AC100-240V / 50-60Hz. Charging time: 6hours, continuous discharging time: more than 15hours at full brightness, over 80hours at back up led brightness.

Type of protection : IMI EXia IICT6 (Zone 1 and 2)

Protection category : IP68



5.Troubles and troubleshootings



Description Analysis Troubleshooting
Light is not bright

Switch contact is bad /

Led source is broken

Inspect switch, measure the circuit, If the switch contact

is good, then check the voltage of LED and the circuit

or contact with the manufacturer.

Not Light enough time Undercharge

First check the contact points, and then charge

according to the regulation .

New lamp use without cycle charge

before

Precycling charge according to the regulations.
The Lifespan of battery is over Replace the new lamp
Illumination is not enough Low battery voltage

Measure the battery voltage, ensure charging time up

to 7hours.

The glass is serious pollution Can wash the lens suface of lamp by water .

The lamp can't charge

or long charging time

Charger (rack) breakdown or battery

damages, charge manager fault

Check the charger 's output voltage and current ,

if all normal, check the battery ,

measure its internal resistance and capacity.

If not up to technical requirements, replace

charger or contact with the manufacturer.

Can't rotate on fixed point The screws of clip is started Fasten the screw appropriately





Correct Use:

The GREEN LIGHTING​ cordless cap lamp is a camera miner’s safety lamp.
The device is attached to a safety helmet, designed to accommodate front mounted attachments, and its power source, battery and housing, is integreted into the cap lamp housing.

The device is primarily designed for underground mining activities and emergency services.

Transportation: The transport process is not allowed by the severe mechanical shock and exposure Rain, prevent throw throwing , rolling, pressure .

Storage: miner's lamp should be stored at ambient temperature 0~40℃,relative bumidity of 45%-90%. Dry, clean ,and wellventilated, non-corrosive medium warehouse, should stay away frion fire and heat, If long-term storage, please filled to 80% of capacity, and charge about 5hours after three to four months.



CAUTION:

This product supports life and health in an underground environment.
Inappropriate use, maintenance or tampering may affect the function of the device and
therefore compromise the product’s ability to support life and protect against harm



ATTENTION:

When using the GREEN LIGHTING​ Cordless Cap Lamp the following safety instructions must be observed:
• Device shall be operated by qualified personnel.
• Before each use, check the functionality of the device.
• Be aware of the procedures for handling electrostatically sensitive electronics, which include
GREEN LIGHTING ​cap lamps.
• This device contains electrostatically sensitive components. Do not open or repair the device without using appropriate electrostatic protection.
• Be aware of the warranty regulations.
• Do not charge in hazardous areas.
• Charge only with approved charging devices.



8.About us

GREEN LIGHTING TECHNOLOGY CO.,LTDis an expertised manufacturer of explosion-proof mining lamps which is located in ShenZhen area in china.Our factory has skilled experience in underground working lamps development and production. We focus on the development and innovation, and we pay more attention to great quality. We also have established our own marketing department for foreign sales.
